Shelf digital signage lcd stretch panel 29 inch stretched lcd display screen

Low Power Consumption,Vivid Visual Feast,Intelligent Split Screen Modes

Specification

                                                                  Panel info Model No. S-CN290P1-V02
LCD Display Double-sided
Display Outline Size(mm) 720.8*226.25*72
Display Area(mm) 705.6(H)x 198.45 mm(V)
Resolution 1920*540
Brightness 700CD/㎡
Pixel Pitch 0.3675
Contract Ratio 1200:01:00
View Angle 89/89/89/89 U/D/L/R
         System CPU S700,Quad-core A53 SMP4,28nm
Operating System Android 5.1.1
RAM 1G
ROM 8G (NAND Flash)
Interface Card Socket PUSH-PUSH TF Card Socket
USB 2Pcs TYPE A(USB OTG&HOST)
Audio out 1 Pcs
RJ45 1 Pcs
Power Jack DC IN
        Internet Wi-Fi 2.4G(802.11b ;802.11 g/n)
LAN 100M
BLE BLE V4.2 of 1, 2 and 3 Mbps
                                      Media play Video Format AVI,MOV, MKV, WEBM,MP4, M4V, FLV, 3GP, 3G2,3GPP,DAT, VOB, EVO,MPG, ASF, TP, TRP, TS, M2TS, MTS etc; S700 support H.265(HEVC)2160P
30fps
Audio Format OGG, APE, FLAC, WAV, AMR, AIFF, MPC.Support multiple Sound Effect
Picture Format JPG、JPEG、BMP、GIF、PNG , etc.maximum resolution to 30000*30000;
Other Parameters Power 65W
Operating Temperature 0℃~50℃
OSD Language Multilingual OSD operation
VESA 16*50mm(M3)
Wireless Display System CMS, Windows OS(Optional)
